SPECIFICATION
Range | 0 to ±1100V DC or peak AC |
Large Signal Bandwidth | DC to 10 Hz (Measured at 2000Vp-p) |
Small Signal Bandwidth | DC to 1 kHz (Measured at 20Vp-p) |
Self-Discharge Rate | Less than 12V/minute |
DC Accuracy | Better than 0.1% of full-scale |
Output Voltage | 1/200th of the plate voltage via BNC |
Input Voltage | 24V DC ±10% |
Dimensions | 318 W x 83 H x 280 D mm |
Weight | 2 kg |
