PRS-801B

Resistance Meter
PRS-801B_1PRS-801B_1
PRS-801B_2PRS-801B_2
PRS-801B_3PRS-801B_3
ESD 관리는 전압 관리가 아닌 방전 제어를 위한 저항 관리가 모든 표준의 관리 기준입니다.
PRS-801 표면 저항 측정기는 도체부터 부도체까지의 (0.1 ~ 2.0xE14 ohms) 저항 측정이 가능합니다.

video

FEATURES

BENEFITS

SPECIFICATION

Measuring Range
0.01 Ω to 2.00 x 1014 Ω
Measurement Modes
Auto, Manual, Auto-Manual, Continuous
Display
6.9 cm x 4.8 cm (2.7” x 1.9″)
6 digit – 7 segment color HTN display
Battery Power
Re-chargeable Li-Ion battery (included). Battery swappable through easily accessible battery door at the rear of the instrument
Battery Charging
Rechargeable via USB 2.0 through PC port or Wall Charger (included)
Battery Charge Indicator
Battery has a status indicator on instrument screen
Battery Charging Time
2 hours
Battery Life
480 hours typical
50 hours (of continuous use)
Approximately 8,000 measurements
Memory Capacity
999 data sets
Memory Data Sets
Data sets include resistance, test voltage, electrification period and timestamp.
Data Download
Compatible with Connect 2.01
USB
USB 2.0 A to Micro-B
Operating Temperature
10°C to 30°C (50°F to 80°F)
Operating Relative Humidity
0% – 85%, non-condensing
Operating Altitude
2000 m
Storage Temperature
-30°C to +60°C (-22 °F to +140 °F)
Dimensions (WxHxD)
117 mm x 188.5 mm x 48 mm
4.59 in x 7.42 in x 1.90 in
Weight
510 g (1.12 lb)
Case Material
Polycarbonate with Rubber Side Grips
Color
Black
Warranty
2 Year Limited Warranty2

제품 구성품
