SPECIFICATION
Output Voltage Range | 0 to ±125V DC or Peak AC 0 to +250V DC or Peak AC 0 to ? 250V DC or Peak AC |
Output Current Range | ±40 mA DC ±80 mA peak AC, for less than 1ms |
Gain | 50V/V (a gain of 25V/V is available) |
Slew Rate
| Greater than 100V/μs (10% to 90%) |
Large Signal Bandwidth | DC to greater than 150 kHz (5% distortion) |
Dimensions | 222.3 W x 108 H x 381 D mm |
Weight | 4.3 kg |
