SPECIFICATION
Construction | Anodised aluminium, epoxy resin, ABS and hardened emitters. |
Cable | 1100 – 14.0 x 17.2 mm, 1100-S – 14.0 x 19.9 mm (W x H). Available Lengths: from 60 mm, to 3000 mm. Active ionisation length = overall bar length – 20 mm. |
Safety | 5 mA maximum current from power unit. High voltage resistance inside bars further limits current below 50 μA. |
Power Unit | Use with Fraser 5.5 kV and 6 kV Power Units. See Datasheets. |
Environmental | 60 °C maximum temperature. 70 % rH non-condensing max. IP66. Fully sealed. |
Certification | CE. UL (US and C) Listing is a free of charge option. |
Options | 1250: with fixed mounting studs. 1250-S: with adjustable mounting studs. 90º cable exit option. Bars joined in series. Air Knife mounted – see 5000/5100 and 5500. Airboost – see 1250 Air Bar. Detachable cable – see 1255. |
Variants | UL Listed version – 1250-S UL. EX-ATEX version – see EX-1250. Please see page 2 for details of all variants. |
