SPECIFICATION
Construction | Stainless steel and PTFE. |
Dimensions | See Broshure |
Cable | Hi-Flex 30 kV screened cable with 70 mm bend diameter. Standard length is 2 m – longer lengths can be specified at time of order (subject to maximum load on power unit). |
Safety | 100 Mohm resistance in series with HV for shockless operation. |
Power Unit | Use with Fraser 5.5kV and 6 kV Power Units. See Datasheets. |
Air Supply | Air Pressure: maximum 7 Bar. Air Consumption: 2 Bar: 180 l/min. 7 Bar: 520 l/min. Air Fitting: push-fit connector for 8mm OD Tubing |
Environmental | 60 °C maximum temperature. 70 % rH non-condensing max. Noise: 76 dBA @ 7 Bar. |
Certification | CE. |
