SPECIFICATION
Construction | PVC body, stainless steel base, tungsten emitter. |
Dimensions | 123 mm x 25 mm x 32 mm (L x W x H). |
Weight | 80 g. |
Outpt Voltage | Up to 3 kV supply integrated into the Ioniser. 65 – 70 kHz. |
Remote Monitor /
Local Status Indication | Two signals available: ‘OK’ and ‘Attention’. Outputs compatible with IEC 61131-2 Type 3 PLC inputs. Signal protected against shorting and miswiring. Three colour LEDS on Ioniser for local status indication. |
Electrical Input | Input: 24 V DC (21 – 28 V), max current 0.1 A. M8 x 4-pin male connector. M8 x 4 core cable to be ordered separately. |
Air Supply | 0 – 5 Bar max. 0.5 – 2.0 Bar optimum. Clean, dry air. Push-fit connector for 6 mm OD tubing. |
Environmental | 0 – 55 °C, 70 % rH non-condensing max. |
Certification | CE. Cleanroom classification ISO Class 4. |
Options | 100 – 250 V AC PSU also available. |
