SPECIFICATION
Construction | Reinforced FR-ABS industrial grade extrusion and endcap, fully encapsulated with epoxy resin. Tungsten emitters. |
Dimensions | 28 mm x 66.5 mm (W x H). Available Lengths: minimum 450 mm, then steps of 150 mm to 4950 mm. |
Weight | 2.6 kg/m. |
Output Voltage | 20 kV supply integrated into bar. |
Remote Monitor / Local Status Indication | 2 signals available: ‘HV OK’ and ‘Attention’. Both outputs are IEC 61131-2 Type 1, Type 2 and Type 3 compatible. The outputs can also be used for direct driving of external lamps or relays. Bi-colour LED on endcap for local status indication, including ‘Clean Me’. |
Electrical Input | 24 V DC (21-28 V), maximum current required 2.0 A. M12 5-pin connector. |
Environmental | 0 – 55 °C, 70 % rH non-condensing max. IP67. |
Certification | CE, CB and UL. |
Options | 100 – 250 V AC-DC 24 V Power Supply (Part No: NEOS-PSU). |
