SPECIFICATION
Input Voltage | 24 VDC, 2.2 W Max. |
Ion Emission | High Frequency AC (70 kHz) |
Balance | Average ≤±10 V, Max ≤±30 V |
Discharge Time | ±1000 V to ±100 V less than 1 sec (15cm) ![]() |
Emitter Points | Tungsten 99.99% |
Alarm | Visual & Audio alarm operate for power failures |
Monitoring | FMS monitoring interface |
Air Pressure | 0.1 – 0.5 Mpa |
Air Inlet | 6mm Inlet |
Material | Enclosure: ABS Plastic Nozzle: Teflon Bracket: SUS |
Dimensions (mm) | 134W x 56H x 25D (without bracket) 134W x 62H x 25D (with bracket) |
Weight | 90g (with bracket) |
Warranty | 1 year limited warranty |
