SPECIFICATION
Range | 0 to ±20,000 Volts
|
Input | < ±2 Volts
|
Circuit Accuracy
| <±1%
|
Interface
| USB 2.0
|
Sampling Rate
| 50, 100 and 200 Samples per second
|
File Limit
| ≈ 1 to 15 minutes per file, continuous recording at 50 samples/second ≈ 7 minutes at 100 samples/second 3.5 minutes at 200 samples/second
|
USB Connector
| USB-C
|
Power | Via USB
|
Compability
| Windows® 10+ 2
|
Material | Plastic |
Length | 2.756″ (70 mm)
|
Width | 1.969″ (50 mm)
|
Height | 0.787″ (20 mm)
|
Weight | 1.2oz (34g)
|
Warranty | 2 year limited warranty
|
